LSC Nexus NXST Ethernet/DMX512 Converter

LSC Nexus NXST Ethernet/DMX512 Converter
Free
  • NXST

The NEXUS NXST is the latest addition to LSC’s Data Distribution products and offers conversion between DMX512A and RDM signals to/from Ethernet and currently supports Art-Net, Shownet and Streaming ACN (sACN) ethernet protocols.

Much more than your standard converter, the NEXUS range of both 1 and 5 port interfaces allows the user many other options such as a protocol conversion tool for today’s demanding shows.

  • Two Ethernet Ports via Neutrik Ethercon connectors.
  • Second Ethernet port can be used as a hub or as a redundant feed.
  • Five data inputs / outputs suitable for DMX512A/RDM compatible protocols.
  • Supports Art-Net, Shownet and sACN protocols.
  • Output XLR connector options of 5 pin or 3pin.
  • Internal 85-265v AC 45-65Hz universal power supply with CE, Ctick and UL approval.
  • Fully opto/earth-isolated input & individually opto/earth isolated outputs.
  • LED indicators for DMX, Power, DMX Termination and DMX/RDM data activity.
  • Output circuits are EMI filtered and current limited to protect against short circuits.
  • Optional Hook Clamp adapter.
  • Safety Wire attachment point.
  • Lightweight, high strength moulded plastic case.

Additional Information

Weight 0.65 kg
Dimensions 320 × 123 × 53 mm
