ETC Source Four Mini LED

ETC Source Four Mini LED

The Source Four Mini LED™ is everything you expect from the Source Four brand – ease of use, superior optics, crystal-clear image projection and a bright, even field – but packaged in a tiny fixture that’s just one-third the size of a traditional Source Four. A mere nine inches long, the Source Four Mini can go anywhere: museums, retail outlets, restaurants, light labs, children’s theaters, and other small scale installations where size matters.

The Source Four Mini is available in four field angles: 19°, 26°, 36° and 50°, with a 2.5-inch diameter lens. It comes in a portable version with a miniature C-clamp, a canopy-mount design with an integral transformer, or a track-mounted design. All Source Four Mini models include an E-sized pattern holder and a gel media frame, with a range of additional accessories.

The Source Four Mini is also designed to work perfectly with DataTrack, ETC’s DMX-ready track lighting solution. With the Source Four Mini and DataTrack, architectural installs can take advantage of the same high-quality dimming, and even beam field ETC is known for.

Features for all Source Four Mini models

  • 19°, 26°, 36° and 50° field angles
  • 9″ long, 2.5″ diameter
  • 12W LED (35,000-hour life)
  • Portable, canopy-mount and track-mount versions
  • E-size pattern holder
  • Gel media frame
  • Rotating barrel ± 175°
  • Three-plane stainless-steel shutter blade assembly
  • Insulated rear handle
  • Rugged die-cast aluminum construction
  • Black, white, silver or custom colors available
